NEEDLE POSITION
1. Put the spool holder on the spool pin.
2. While using large cone spool use spool holders which are located in the
accosory box.
3. Put the thread spool on the spool holder.
This machine has
four dierent needle
positions. Up to two
needles can be stitched
at the same time. Fixed
screw A belongs to the
right side of the needle.
Fixed screw B belongs
to the left side of the
needle.
Fixed screw C
belongs to 2-thread
chain stitch of
the needle. Fixed
screw D belongs
to overlock of the
needle.
As shown on the gure, installing the needles in dierent positions will eect in a
dierent stitch.
A
B
A
B
C
C
D
D
Note: If 2-thread chainstitch and cover stitch needles thread, the left needle is
slightly higher than the right needle.
Right overlock
needle thread
2-thead chainstitch
needle thread
Left overlock
needle thread
Cover-stitch needle
thread
Left and right overlock needles thread
2-thread chainstitch and cover-
stitch needles thread
