CD397-Oper Operation - 2 - 9
June 2019 (Rev C)
Operation Mobile Belt Loader Model 660-28
Section 2 Operation Manual
2.3.3DrivingInstructions
The foot throttle is a conventional automobile accelerator connected to the ECM by electrical connection.
• To increase speed, depress foot throttle.
• To decrease speed, release foot throttle.
2.3.3.1TransmissionSelection
To select a vehicle drive direction in a USA configured belt loader:
1. Move transmission drive selector lever up (toward instrument panel) to select reverse direction.
2. Move transmission drive selector lever down (toward driver’s seat) to select forward direction.
3. Neutral is located midway between forward and reverse and is indicated by a positive stop notch
into which the spring loaded lever will fall when shifting.
4. Select transmission drive (FWD/REV).
2.3.4ConveyorManeuvering
2.3.4.1ApproachingtheAircraftwithsteeringwheel
The steering system is hydraulic type powered from the hydraulic pump.
1. Approach the aircraft to a distance of two or three feet.
2. Move transmission selector to Neutral.
3. Apply park brake.
2.3.4.2LoadingandUnloadingbaggage
1. Raise the front and rear of the conveyor to the correct heights for the aircraft.
2. Release the park brake.
3. Move transmission selector to FWD and slowly approach the cargo door opening.
4. When in the correct position, move the transmission selector to Neutral.
5. Apply the park brake.
6. Make final height adjustments.
7. Load/unload the baggages from the aircraft.
2.3.4.3DepartingtheAircraft
When baggage is loading/unloading is complete, follow the above steps in reverse order.
NOTE:
This transmission is equipped with Abuse Protection Valve Body. To shift into Reverse (R) or
Forward (F), all three of the following conditions must be met:
1. Throttle position must be less than 25%.
2. Engine RPM must be less than 1500 RPM.
3. Vehicle speed must be 0 MPH.
If any of the above conditions are not met, the transmission will be placed into a neutral
state until all three conditions are met. This neutral state may slightly drag the forward or
reverse clutch, moving the vehicle very slowly and give the impression that the transmission
is slipping. To fully engage the desired gear, simply come to a complete stop with the engine
at idle.
