Technical Information
Service Manual
Model
GWHART12SA2
GRHART12ASA2
GWHART12S2
GRHART12AS2
Product Code CB464008700_116777 CB464008500_116777
Power
Supply
Rated Voltage V~ 115 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity Btu/h 12000 12000
Heating Capacity Btu/h 12000 12000
Cooling Power Input W 1062 1062
Heating Power Input W 992 992
Cooling Power Current A 11.5 5.0
Heating Power Current A 10.8 4.8
Rated Input W 1450 1450
Rated Cooling Current A 15.8 6.8
Rated Heating Current A 15.8 7.0
Air Flow Volume CFM 400/365/330/288/265/247/230 400/365/330/288/265/247/230
Dehumidifying Volume Pint/h 2.96 2.96
EER (Btu/h)/W 11.30 11.30
COP (Btu/h)/W 12.10 12.10
SEER 20(SEER) 20(SEER2) 20(SEER) 20(SEER2)
HSPF 10(HSPF) 8.5(HSPF2) 10(HSPF) 8.5(HSPF2)
Application Area yd
2
19-29 19-29
Indoor
Unit
Model of indoor unit GWHART12SA2 GWHART12S2
Indoor Unit Product Code CB464N08700_116777 CB464N08500_116777
Fan Type Cross-ow Cross-ow
Fan Diameter Length(D×L) mm Ф98×633.5 Ф98×633.5
Cooling Speed r/min 1400/1200/1120/1050/950/850/750/500 1400/1200/1120/1050/950/850/750/500
Heating Speed r/min 1400/1200/114/1080/1020/960/900 1400/1200/114/1080/1020/960/900
Fan Motor Power Output W 20 20
Fan Motor RLA A 0.30 0.25
Fan Motor Capacitor μF / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ5 Φ5
Evaporator Row-n Gap mm 2-1.4
2-1.4
Evaporator Coil Length (L×D×W) mm 635×22.8×306.3 635×22.8×306.3
Swing Motor Model MP24HF MP24HF
Swing Motor Power Output W 1.5 1.5
Fuse Current A 3.15 3.15
Sound Pressure Level dB (A)
Cooling: 44/39/37/35/32/30/27
Heating: 45/39/38/36/34/32/31
Cooling: 44/39/37/35/32/30/27
Heating: 45/39/38/36/34/32/31
Sound Power Level dB (A)
Cooling: 54/49/47/45/42/40/37
Heating: 55/49/48/46/44/42/41
Cooling: 54/49/47/45/42/40/37
Heating: 55/49/48/46/44/42/41
Dimension (W×H×D) inch 33 17/64×11 3/8×8 15/64 33 17/64×11 3/8×8 15/64
Dimension of Carton Box (L×W×H) inch 35 7/16×13 13/16×10 45/64 35 7/16×13 13/16×10 45/64
Dimension of Package (L×W×H) inch 35 5/8×14 29/64×11 9/64 35 5/8×14 29/64×11 9/64
Net Weight Ib 22.1 22.1
Gross Weight Ib 26.5 26.5
