59
Installation and Maintenance
Service Manual
8.1 Installation Dimension Diagram
8. Installation
At least 15cm
A
At least 250cm
Space to the ceiling
t least 15cm
Space to the wall
At least 15cm
Space to the wall
At least 300cm
Space to the obstruction
Space to the floor
Drainage pipe
Space to the obstruction
At least 50cm
Space to the obstruction
At least 30cm
At least 50cm
Space to the obstruction
Space to the obstruction
At least 200c
m
Space to the wall
At least 30cm
