TGM YAP1FF - Outdoor Unit

23
Technical Information
Service Manual
3.2 Outdoor Unit
3. Outline Dimension Diagram
12 13/64
17 29/32
11 7/32
21 27/32
12 63/64
26 37/64
28 13/16
GRHART09ASA2 GRART09AS2 GRHART09AS2 GRART12ASA2 GRHART12ASA2
GRART12AS2 GRHART12AS2
GRART18AS2 GRHART18AS2
Unit:inch
34 24/64
14 51/64
13 1/64
21 54/64
20 25/32
Unit:inch
