Technical Information
Service Manual
2. Specications
2.1 Specication Sheet
Model
GWHART09SA2
GRHART09ASA2
Product Code CB464007300_116777
Power
Supply
Rated Voltage V~ 115
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity Btu/h 9100
Heating Capacity Btu/h 10000
Cooling Power Input W 850
Heating Power Input W 862
Cooling Power Current A 9.24
Heating Power Current A 9.37
Rated Input W 1310
Rated Cooling Current A 12.50
Rated Heating Current A /
Air Flow Volume CFM 318/288/265/241/218/194/171
Dehumidifying Volume Pint/h 1.69
EER (Btu/h)/W 10.70
COP (Btu/h)/W 11.60
SEER 18(SEER) 18(SEER2)
HSPF 9.5(HSPF) 8.5(HSPF2)
Application Area yd
2
14-22
Indoor
Unit
Model of indoor unit GWHART09SA2
Indoor Unit Product Code CB464N07300_116777
Fan Type Cross-ow
Fan Diameter Length(D×L) mm Φ98×580
Cooling Speed r/min 1350/1200/1120/1050/950/850/750
Heating Speed r/min 1350/1200/1130/1050/990/920/850
Fan Motor Power Output W 20
Fan Motor RLA A 0.24
Fan Motor Capacitor μF 4
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ5
Evaporator Row-n Gap mm 2-1.4
Evaporator Coil Length (L×D×W) mm 584×22.8×266.7
Swing Motor Model MP24AA
Swing Motor Power Output W 1.5
Fuse Current A 3.15
Sound Pressure Level dB (A)
Cooling: 41/38/36/34/32/30/28
Heating: 42/38/36/34/32/30/28
Sound Power Level dB (A)
Cooling: 51/48/46/44/42/40/38
Heating: 52/48/46/44/42/40/38
Dimension (W×H×D) inch 31 7/64×10 53/64×7 7/8
Dimension of Carton Box (L×W×
H) inch 33 15/32×13 11/32×10 5/16
Dimension of Package (L×W×H) inch 33 35/64×13 31/32×10 3/4
Net Weight Ib 19.8
Gross Weight Ib 24.3
