4
Technical Information
Service Manual
2. Specications
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Unit
Outdoor Unit Model GRHART09ASA2
Outdoor Unit Product Code CB444W15300_116777
Compressor Manufacturer ZHUHAI LANDA COMPRESSOR CO.,LTD
Compressor Model QXF-N075zC170A
Compressor Oil FW68DA
Compressor Type Rotary
Compressor LRA. A -
Compressor RLA A 11.20
Compressor Power Input W 640
Compressor Overload Protector /
Throttling Method Capillary
Set Temperature Range ºF 61~86
Cooling Operation Ambient Temperature
Range
ºF 0~118
Heating Operation Ambient Temperature
Range
ºF -13~75
Condenser Form Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ7
Condenser Rows-n Gap mm 1-1.2
Condenser Coil Length (L×D×W) mm 666×19.05×528
Fan Motor Speed rpm 900
Fan Motor Power Output W 30
Fan Motor RLA A 0.40
Fan Motor Capacitor μF /
Outdoor Unit Air Flow Volume CFM 1148
Fan Type Axial-ow
Fan Diameter mm Φ400
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating Pressure
for the Discharge Side
MPa 4.3
Permissible Excessive Operating Pressure
for the Suction Side
MPa 2.5
Sound Pressure Level dB (A) 51
Sound Power Level dB (A) 61
Dimension (W×H×D) inch 28 13/16×21 27/32×12 63/64
Dimension of Carton Box (L×W×H) inch 31 9/64×14 11/16×23 15/64
Dimension of Package (L×W×H) inch 31 17/64×14 51/64×24 7/32
Net Weight Ib 59.5
Gross Weight Ib 65.0
Refrigerant R410A
Refrigerant Charge oz 24.0
Connection
Pipe
Connection Pipe Length ft 24.6
Connection Pipe Gas Additional Charge oz/ft 0.2
Outer Diameter Liquid Pipe inch 1/4
Outer Diameter Gas Pipe inch 3/8
Max Distance Height ft 32.8
Max Distance Length ft 49.2
Note: The connection pipe applies metric diameter.
