TGM YAP1FF - Outline Dimension Diagram; Indoor Unit

21
Technical Information
Service Manual
3. Outline Dimension Diagram
3.1 Indoor Unit
Model W H D
GWHART09SA2
31 7/64 10 53/64 7 7/8
GWART09S2
GWHART09S2
GWART12SA2
GWHART12SA2
GWART12S2
GWHART12S2
33 17/64 11 3/8 8 15/64
GWART18S2
GWHART18S2
38 3/16 11 13/16 8 55/64
GWART24S2
GWHART24S2
42 28/64 12 51/64 9 44/64
Unit:inch
W
D
H
3 1/2
6
2 1/8
2 1/8
6 5/8 18 3/16 6 5/16
Φ2 3/16
Φ2 3/16
Φ2 3/16
Φ2 3/16
4 11/1621 5/16 1/4 7
3 5/16
5
1 3/8
1 3/8
472 7 3/16
5 1/2
7 1/2
1 1/2
Φ2 3/16
Φ2 3/16
3 1/8
6
1 11/1
6
8 1/827 7 5/16
Φ2 3/4
Φ2 3/4
GWHART09SA2
GWART18S2 GWHART18S2
GWART09S2 GWHART09S2 GWART12SA2
GWHART12SA2 GWART12S2 GWHART12S2
GWART24S2 GWHART24S2
