5
Technical Information
Service Manual
Model
GWART09S2
GRART09AS2
GWHART09S2
GRHART09AS2
Product Code CB464006900_116777 CB464007000_116777
Power
Supply
Rated Voltage V~ 208/230 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity Btu/h 9100 9100
Heating Capacity Btu/h / 10500
Cooling Power Input W 700 728
Heating Power Input W / 808
Cooling Power Current A 3.45 3.45
Heating Power Current A / 3.9
Rated Input W 1350 1450
Rated Cooling Current A 6.5 6.5
Rated Heating Current A / 7
Air Flow Volume CFM 371/318/253/194 371/318/253/194
Dehumidifying Volume Pint/h 1.69 1.69
EER (Btu/h)/W 13.00 12.50
COP (Btu/h)/W / 13.00
SEER 20.5(SEER) 20.5(SEER2) 20.5(SEER) 20.5(SEER2)
HSPF / 10(HSPF) 8.8(HSPF2)
Application Area yd
2
14-22 14-22
Indoor
Unit
Model of indoor unit GWART09S2 GWHART09S2
Indoor Unit Product Code CB464N06900_116777 CB464N07000_116777
Fan Type Cross-ow Cross-ow
Fan Diameter Length(D×L) mm Ф98×633.5 Ф98×633.5
Cooling Speed r/min 1350/1200/1000/800 1350/1200/1000/800
Heating Speed r/min / 1300/1200/1050/850
Fan Motor Power Output W 20 20
Fan Motor RLA A 0.32 0.32
Fan Motor Capacitor μF 1.5 1.5
Heater Power Input W / 72
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ5
Φ5
Evaporator Row-n Gap mm 2-1.4 2-1.4
Evaporator Coil Length (L×D×W) mm 635×22.8×306.3 635×22.8×306.3
Swing Motor Model MP24HF MP24HF
Swing Motor Power Output W 1.5 1.5
Fuse Current A 3.15 3.15
Sound Pressure Level dB (A) Cooling: 42/39/34/27
Cooling: 42/39/34/27
Heating: 42/39/35/29
Sound Power Level dB (A) Cooling: 52/49/44/37
Cooling: 52/49/44/37
Heating: 52/49/45/39
Dimension (W×H×D) inch 33 17/64×11 3/8×8 15/64 33 17/64×11 3/8×8 15/64
Dimension of Carton Box (L×W×H) inch 36 9/64×10 15/16×14 21/64 36 9/64×10 25/32×14 21/64
Dimension of Package (L×W×H) inch 36 17/64×11 1/16×14 59/64 36 17/64×11 1/16×14 59/64
Net Weight Ib 22.1 22.1
Gross Weight Ib 26.5 26.5
2. Specications
