24
Technical Information
Service Manual
3. Outline Dimension Diagram
37 23/32
35 13 25/64
15 53/64
25 63/64
22 7/16
14 41/64
Unit:inch
39 3/8
36 11/32
14 17/32
16 13/16
29 3/8
24 1/64
15 35/64
Unit: inch
GRART24AS2 GRHART24AS2
GRART36AS3 GRHART36AS3
