TGM YAP1FF - Page 33

30
Technical Information
Service Manual
5. Electrical Part
600007066414
GWART36S3 GWHART36S3
MAIN BOARD
AP2
JUMP
CAP
COM-OUT
N(N1)
AP3
STEPPING
MOTOR
M3
UP-DOWN
SWING-LR1
M4
SWING-LR2
M2
STEPPING
MOTOR
LEFT-RIGHT
SWING-UD
BLOCK
TERMINAL
3
2
N(1)
XT1
OUTDOOR UNIT
DISP1 DISP2
AC-L
STEPPING
MOTOR
LEFT-RIGHT
MOOREBUT
RT2
θ
TUBE TEMP.
SENSOR
RT1
θ
ROOM TEMP.
SENSOR
COM-MANUAL
AP5
WIRED
CONTROLLER
WH(BU)
BK
RD(BN)
GN(YEGN)
AP4
Please don't touch any
electronic component or
terminal when the machine
is running,stopping or has
been powered off for less
than 3 minutes to prevent
electric shock !
DISPLAY
RECEIVER AND
DISPLAY BOARD
AP1
OPTIONAL
OPTIONAL
G
EVAPORATOR
YEGN
DC-MOTOR
M1
FAN MOTOR
BN
BK
BU
WIFI
MODULE
OPTIONAL
OPTIONAL
GATE
CONTROL
DOOR-C
(DRY-C)
WARNING
WIFI
