Tharo Systems H-435+ - Page 61

INTERFACE
57
Pin NO.
1
2
3
4
Function
VBUS
D-
D+
GND
86%3RUW
=
Computer Connector: Type A
Pin NO.
1
2
3
4
Function
VBUS
D-
D+
GND
Connector Type: Type B
(WKHUQHW3RUW5-
=
PIN NO.
FUNCTION
1
T+
2
T-
3
R+
4
N/C
5
N/C
6
R-
7
N/C
8
N/C
$SSOLFDWRU3RUW2SWLRQDO
=
PIN NO.
1
2
3
4
5
6
7
FUNCTION
Print
Signal
+5 V
Printer
Error
Signal
+24 V
Printed
Signal
Printing
Signal
Ground
APPENDIX
