Orion Benchtop pH/ISE Meter Instruction Manual
Overview of Meter Functions 520Aplus,525Aplus,720Aplus and 920Aplus
109
Automatic Datalog Function
The meters have an internal datalogger that will record and store a
maximum of 25 points automatically. The data points remain in memory
until cleared.
Prompt Keypress/Action
Press data/print modes
1. MANUAL PRINT The current print mode is displayed. Wait
for the prompt.
2. SET PRINT MODE ? Press no.
3. DATALOG The current datalog setting is displayed.
MANUAL Wait for prompt.
4. SET LOG MODE Press yes.
5. 0-DISABLE 1-RDY The datalog setting options are presented
2-TIM 3-MAN two at a time. Press no to display the other
two. Enter 0, 1, 2 or 3, then press yes.
0To disable datalogging.
1 For datalogging on ready.
2 For datalogging at present time
interval.
3 For manual datalogging when print
is pressed.
6. DATALOG The meter verifies the setting and returns to
MANUAL measure mode.
7. TIMED LOG If 2 (datalog at a preset time interval) is
selected the interval must be entered at the
following prompts.
8. DATALOG INT HR Enter the datalog interval hours setting, from
0 to 23, then press yes.
9. DATALOG INT MIN Enter the datalog interval minutes setting,
from 0 to 59, then press yes.
10. DATALOG INT SEC Enter the datalog interval seconds setting
from 0 to 59, then press yes. Logging can
not take place faster than every 5 seconds.
11.DATALOG The datalog interval is displayed then the
INTERVAL meter returns to MEASURE mode.
