The pellet stove is supplied with built-in circulation pump, expansion vessel and
safety valve. On the back of the stove is the connection for: power supply 230VAC,
50Hz with main switch, fuse and room thermostat.
5.2.1 Power supply
The stove needs to be connected to a 220V, 50Hz via a separate fuse 6-10A (FAST).
5.2.2 Room thermostat
The user has the possibility to place the room thermostat in one room and does not
need to be in the same room where the pellet stove is. Operation of the stove with an
external thermostat connected to the room thermostat connection may differ if we
have activated the STAND BY function. The connection for the room thermostat comes
from the factory with a bridged connection, wich means that its contacts are closed.
Only room thermostats with potential-free contacts may be connected. It is
recommended that the installation and connection of the room thermostat be carried
out by an authorized service technician.
