Product overview
7
1.2 Part names
1.2.1 Front camera (main unit) - front view
GPS port
Used to connect the external
GPS receiver (optional) for
additional features.
Mount connector
Used to connect the mount.
Front camera lens
Records the front view.
Memory card slot
Insert a memory card to save recordings.
Wi-Fi button
Press to connect the product to a
smartphone via Wi-Fi network.
1.2.2 Front camera (main unit) - rear view
Status LED
Indicates the operating
status of the product.
Speaker
Outputs the voice guide and buzzer
sounds to indicate the product’
s status.
DC-IN power port
Used to connect the power cable.
REC button
•
Short Press: Starts manual recording
• Press and hold for 3 seconds:
Audio recording ON/OFF
•
Press and hold for 5 seconds:
Memory card format
Microphone
Used for voice recording.
