Thinky ARV-310 - Specifications

2. Outline and Specifications
ARV-310 2-3
2-2 Specifications
Product Vacuum mixer “Thinky Mixer”
Model ARV-310
Method Vacuum-type, planetary, propeller-less mixing
method
Operating time
setting range
0 sec. – 30 min. (Max. 30 min. run/Setting in the
unit of 1 sec.)
Revolution speed Max. 2,000 rpm (0 rpm and 200 rpm – 2,000
rpm / Increment per 10 rpm)
Rotation speed Max. 1,000 rpm (1/2 of revolution speed)
Standard container
Inner volume: 300 ml and 150 ml、Material: HDPE
For 300 ml-container: 250 ml, 310 g (net weight)
At ambient
pressure:
For 150 ml-container: 150 ml, 310 g (net weight)
For 300 ml-container: 200 ml, 310 g (net weight)
Max.
mixing
volume
At vacuum
For 150 ml-container: 120 ml, 310 g (net weight)
Vacuum chamber Rotating part vacuum chamber
Vacuum pump
capacity
266 Pa (About 2 Torr), 100 lit./min.
Vacuum pump oil
SAE #10（ISO #VG32）
Ultimate pressure in
vacuum chamber
660 Pa (About 5 Torr) at use of jER (epicoat)
#828
（＊）
Ultimate pressure
reaching time
Less than 1 min. to reach 2.66 Pa (About 20
Torr) at use of jER (epicoat) #828
（＊）
Time for releasing
pressure in vacuum
chamber to ambient
pressure
Less than 20 sec. (Duration of time till air is
released to ambient pressure)
Voltage
Single phase, 100Vac±10%, 50/60 Hz
Supply
power
Consumption
power
At standby: 50 VA, During operation: Max.
1,000 VA (excl. start time)
