3. Installation
ARV-310 3-7
3-4 Removal of Shipping Locks
The Thinky ARV-310 is locked with two (2) fasteners for fixing
the unit’s rotating mechanism and preventing damages during
shipment.
Loosen the shipping locks in the following procedure to install
the mixer.
1) Turn the front-side shipping lock screw with the
standard box wrench clockwise until the wrench stops.
・ The fixed rotating mechanism base part on the front side
is released.
・ The shipping lock screw is a reverse screw (loosened in
CW turning). Turn the screw clockwise to release the
shipping lock.
・ When the shipping lock screw is turned clockwise, the
portion circled in the figure below moves to the right and
the shipping lock is released.
Front-side Shipping Lock Screw
To Next Page
