2. Insert the four Phillips-head barrel nuts (12) into the rear panel of the pedal
box (8) as shown in the left part of the figure. Use two screws 6 ´ 50 (9) on each
side to attach the two side panels to the pedal box and cover the four screws
with screw caps (10).
3.
Attach the speakers with each two screws 6 ´ 50 (9) to the side panels (2) and
(11) and cover the screws with screw caps (10).
4. Put the digital piano housing (1) on the stand and affix it using the two hand
screws (7).
Assembly instructions
DP-33
11
