Socket spanner
190.295 Socket spanner SW 17
Tube for Template Ø 20, 26 et 30 mm
(allow welding of studs through templates with different diameter holes.)
190.30x
Complete Assembly:
190.310 1. Face plate
190.315 2. Spacer ( x 3 )
190.320 3. Screw-in ring
190.325 4. Centring rod
190.33x 8. Nose cone
190.34x 9. Centring cup
190.045 Longer Chuck Screw
x = 1 for Ø 20 mm.
x = 5 for Ø 26 mm.
x = 7 for Ø 30 mm.
Longer Chuck Back stop Screw
190.045 Chuck Back stop
Offset chuck attachment
190.012 Offset chuck attachment
The Angled Extension Arm
allows the welding of studs
into corners and against
upstands.
CD tester bending bar
Bending bar nozzle Ø 3 mm
Bending bar nozzle Ø 4 mm
Bending bar nozzle Ø 5 mm
Bending bar nozzle Ø 6 mm
Bending bar nozzle Ø 8 mm
70
