U201 2.6V +/-5%
C817(+) 1.19V +/-5%
Download latest release MCU_SW into the Standby CPU(U810) using WT_MCU_ISP SW tool. See
Appendixn “How to download MCU SW”.
Download latest release SW into the flash using MTK SW tool. See Appendixo
“How to download
FLASH SW”. Or download the SW from USB port.
1.2. Functional Test
Once the boards (chassis, FAV, KB, IR, PSU…) and the panel are well interconnected, connect all
external generator devices to relevant inputs/outputs below according to their respective test
patterns format and check picture content and sound quality accordingly:
Source Test signal (generator) Test pattern (format/image)
Analog /Digital Tuner RF cable Full Band (VHF/UHF) + CATV DVB-T
SCART1 (CVBS) Chroma/Fluke PAL Half Color & Gray bars
Side av (cvbs)–
SVideo(Y/C)
Chroma/Fluke PAL Half Color & Gray bars
SCART1 (RGB) Chroma/Fluke Half Color & Gray bars
SCART1 (CVBSOut) RF cable First channel
HDMI DVD with HDMI
compliancy
Movie 720p@60Hz
VGA Chroma/QuantumData 1024x768@60Hz
Half Color & Gray bars
Headphone RF cable First channel
Loud Speakers RF cable First channel
CMP (YPrPb) Chroma/QuantumData 1080i@60Hz
Half Color & Gray bars
Audio tones can be defined by the factory (ie: 1KHz & 3KHz, sweep, …).
Picture video formats can be changed by the factory according to their own standard.
1.3. ADC Calibration
Two inputs require an ADC calibration for the time being, That are:
VGA
Provide a test signal 1024×768@60Hz with White Black squares.
Select the corresponding “Auto Color” submenu item from “Factory Menu”, then press ”OK” to
start.
When VGA channel is aligned, SCART-RGB is also aligned, so it is not necessary for RGB to be
separately aligned.
CMP
Provide a test signal 576i@50Hz with 100% 8 steps Color Bar.
Select the corresponding “Auto Color” submenu item from “Factory Menu”, then press ”OK” to
start.
