Matrix Offsets”. Those offsets values don’t require any alignment but can be fine-tuned in Factory
Menu as well.
<The appendix is just a template, Every lot the relative offset is different. We need to align 5 sets
first to get the relative offset data every lot. >
Expected Targets and Tolerances
The measured parameters should be “x, y” coordinates.
The White Balance alignment should be performed using a contact less analyzer (ei: Minolta
CA-210). The analyzer may not touch the screen surface, and measurement must be performed in
a dark environment keeping the probe(s) at 90+/-2° from the panel.
The alignment has to fulfill the requirements in Application Form.
2.4. High Pot. and Insulating Resistance Tests
At the end of the process, a High Pot. and an Insulating Resistance tests are required for
matching Safety Electrical requirements (ei: xxxx)
High Voltage Withstanding requirements
- “Voltage” Ö 4240 VDC
- “Max Leakage Current” Ö 1 mA
- “Test Time” Ö 3 sec
Insulating Resistance requirements
- “Voltage” Ö DC500V
- “Threshold Max” Ö
- “Threshold Min” Ö 4MΩ
- “Test Time” Ö 3 sec
3. “Factory Menu” Definition
1)． System
Item Sub-item
Factory Key OFF：Factory Key is invalidation
ON ：Factory Key is availability, and BLUE key is the shortcut key.
Note: option step
1）Enter menu
2）7915
3）Exit/Enter menu
4）Enter Factory Item
Enter Factory menu .(Or Enter Factory mode by hotkey )
Burning Mode Off/On
Power Mode Boot/Standby/Previous
Boot: Enter power on mode
Standby: Enter standby mode
