MT5335PU Approval Datasheet
DOCUMENT ARE SUBJECT TO CHANGE WITHOUT NOTICE
MTK CONFIDENTIAL, NO DISCLOSURE
4/14
Supports 64 Mb to 512 Mb DDR DRAM devices
The MT5335PU supports 16-bit data bus; address offers up to 64 M bytes space.
Supports DDR1-333, DDR1-400, DDR2-400, DDR2-533, DDR2-667, DDR2-800
Audio DSP
Supports Dolby Digital AC-3 decoding
MPEG-1 layer I/II decoding (DVB)
Dolby Prologic II
Audio output: 7.1ch + 2ch (down mix)
Pink noise and white noise generator
Equalizer
Bass management
3D surround processing with virtual surround
Audio and video lip synchronization
Supports reverberation
Automatic volume control
One SPDIF out
If internal audio DAC is disabled, the MT5335PU supports 1-bit (2-channel) main audio I
2
S output
interface. Each channel is up to 24-bit resolution.
Flash Interface
The MT5335PU supports two one serial flash
Serial flash interface supports up to 60 MHz clock rate, depending on the spec. of the flash device
(currently 20 MHz at maximum)
Supports on-the-fly decompression from Serial Flash to DRAM
Peripherals
The MT5335PU has one dedicated UART and one shared UART with GPIO.
The MT5335PU has three basic serial interfaces; one is for the tuner, one is the master for general
purpose and the other is the slave for HDMI EDID data.
Three PWMs
IR blaster and receiver
Real-time clock and watchdog controller
1-port USB2.0/1.1 host supports USB mass storage class devices.
Supports five-channel servo ADC.
IC Outline
The MT5335PU is 256-pin LQFP-EPAD Package
3.3V/1.1V and 2.5V for DDR1, 1.8V for DDR2
