Chapter 4 Standalone Operation
4.4.2 Menu Option - Go to position count
This option is used to move the motor associated with the
selected channel to a specific position. The position is
measured in cycles (pulses) relative to the zero position,
in the range -100000 to 100000.
Push the CHANNEL SELECT button to select the
required motor channel.
Press the MENU button, then use the joystick to scroll
through the menu options.
Press the MENU button to enter the Go to Pos Count
option.
Use the joystick to set the required position count, in the
range -100000 to +100000.
Press the MENU button to save the setting and return to
the operating screen.
The display shows position count for the channel
selected, which counts up or down until the target is
reached.
MENU
KIM101
KIM101
Enabled Axis CH1
Ch1_X1 +0
Ch2_Y1 +0
Ch3_X2 +0
Ch4_Y2 +0
KIM101
Enabled Axis CH1
Ch1_X1 +23000
Ch2_Y1 +0
Ch3_X2 +0
Ch4_Y2 +0
Menu options
Use joystick
KIM101
Menu options
1 Goto Pos Count
KIM101
Ch1 0
to set count
KIM101
Ch1 23000
to set count
MENU
MENU
