THORLABS KIM101 User Manual

Page 21 ETN040053-D03
K-Cube Inertia Piezo Motor Driver
4.4.3 Menu Option - Zero Axis
Zeroing is equivalent to homing in a stepper or DC motor
in that it establishes a datum from which subsequent
position moves can be measured. Unlike these other
motors however, the piezo motor can be zeroed
anywhere along its travel.
Push the CHANNEL SELECT button to select the
required motor channel (or channels), then move each
motor in turn to the required zero position.
Press the MENU button, and use the joystick to scroll
through the menu options.
Press the MENU button to enter the Zero Axis option.
Use the joystick to select the motor channel to be zeroed,
or select Zero All Chan to zero all motor channels at their
present positions.
Press the MENU button to zero the channels and return to
the main display.
The display shows the zeroed position count for the
channel(s) selected.
MENU
MENU
KIM101
KIM101
Enabled Axis CH1
Ch1_X1 +23000
Ch2_Y1 +0
Ch3_X2 +0
Ch4_Y2 +0
Enabled Axis CH1
Ch1_X1 +0
Ch2_Y1 +0
Ch3_X2 +0
Ch4_Y2 +0
Menu options
Use joystick
KIM101
Menu options
2 Zero Axis
KIM101
Select Channel
to Select
KIM101
KIM101
Zero All Chan
to Select
MENU
