9
Control Functions
LEFT HANDLEBAR
Engine Stop Switch
“OFF” position
e ignition is o, e engine cannot start or run
“HUN” position
e ignition circuit is on the engine can run.
Rear Brake Lever
Apply the rear brake by squeezing the rear brake lever towards the grip
Parking Brake Knob
is knob is used to set the parking brake which is used to prevent the
ATV from moving when it is parked, being started or at idle. Set the park-
ing brake by squeezing the rear brake lever and pushing the knob to lock
the lever in the squeezed position.
Engine Start Switch
Depress the button with the vehicle while in braking mode to start the
engine.
