This interface shows some system input information, such as limiter status, the status of
the water protecting, and the status of the foot switch etc.. When the input is validated, the
color frame will be red, otherwise it’s gray.
4.6.19 Screen Origin
If the “Screen Origin” item is pressed, the system will show as below:
Top left
Origin locat：
Modified press Enter
To modify pressß /à
There are four entries to be selected: Top Left, Top Right, Bottom Left and Bottom Right.
When one is selected, the previewed graph on the screen would be enantiomorphous
based on X or Y direction.
This item is only used to preview the file on the screen, and it is no
meaning to the machine’s movement.
Caution
