4.5 How to adjust focus distance by manual or auto
1). If there’s no auto focus function for your machine or there’s fault for your auto focus,
you can refer to below instructions about how to adjust focus by manually:
1. For standard laser head:
find the 6mm Acrylic Focus Tool for help to adjust the focus directly like below:
①Working Table
②Material
③Focus Tool
If the focus tool is not the best one for your material, you can use the focus ruler for help
like below:
①Working Table
②Material
③Focus Ruler
Please note that the limit line of the head, this limit line indicates the max height of laser
head, and keep the limited line inside the laser head mount. So as to protect the laser
head from crashing into the honey comb table while z-axis does reset/auto focus
