2. For HR laser head
Since HR head is very sensitive for focus distance, thus we’ve tested and made a special
focus tool (with a best distance) for each HR head, like below:
①Working Table
②Material
③The Best Focus Distance
④Focus Tool
Please note that the limit line of the head, this limit line indicates the max height of laser
head, and keep the limited line inside the laser head mount. So as to protect the laser
head from crashing into the honey comb table while z-axis does reset/auto focus
3. For 4’’ laser head
4” laser head is not so sensitive for focus distance; you can set the distance about
10mm with the help of focus ruler
①Working Table
②Material
③Focus Rule
PS: Please keep the 4’’ laser head to the max height of laser head
