4.6 How to use the display
4.6.1 Function of the Buttons
Arrow buttons: control the movement of the laser
head.(also can be used to change the parameters in the control panel)
Z/U button: The Z/U key can be pressed when the system is idle or the work
is finished. On pressing this key, it will show some entries in the interface, each entry
includes some functions, Z axes move, U axes move, each axes to go home etc.
Reset button: reset the machine.
Pulse button: single press to draw a dot, press and hold to drill a hole.
Speed button: Set the speed of the current running layer, or set the
direction keys’ move speed.
Min-Power button: Set the min laser power of the current running layer.
To Next Page
