18
•Move the throttle/collective stick to the full throttle position(see upper right diagram). The molded "pointer"
should now line up with the upper limit mark, which should provide about 12˚ of blade pitch.
•Move the throttle/collective stick to the low stick position. Use the ATV function of your transmitter to make
the "pointer" line up with the 0˚ mark for beginners(with the -4˚ mark for intermediates, and -8-degree
mark for experts).
Throttle at High Position
Throttle at Low Position
•High End Blade Pitch Setting
•Low End Blade Pitch Setting
Linkage Position for beginner
