19
Collective Travel for F3C and 3D Flying
•To achieve +12˚ to -8˚ of collective travel range, the steel linkage ball must be moved to the inner
location as shown in the figure.
•Use ATV function of the transmittler to get the necesary servo travel.
The molded "pointer" should line up with the upper limit mark, which
should provide about 12˚ of blade pitch.
For intermediates set the low end to -4˚. For advanced F3C and 3D flying,
set the low end to -8˚.
Throttle at High Position
Throttle at Low Position
•High End Blade Pitch Setting
•Low End Blade Pitch Setting
Linkage Position for F3C or 3D
Position for F3C or 3D
