ThyssenKrupp TAC 32 User Manual

Owner’s Manual
E2010 THYSSENKRUPP ELEVATOR Printed in USA February, 2010
Traditional Signal Fixtures-5
Car Braille
Part No. Print No. Description
9796241 Plate, Round, 1 3/8”, #4 SS, ”1”
9797142 Plate, Round, 1 3/8”, #4 SS, ”10”
9797245 Plate, Round, 1 3/8”, #4 SS, ”11”
9797348 Plate, Round, 1 3/8”, #4 SS, ”12”
9797440 Plate, Round, 1 3/8”, #4 SS, ”13”
9797543 Plate, Round, 1 3/8”, #4 SS, ”14”
9797646 Plate, Round, 1 3/8”, #4 SS, ”15”
9769344 Plate, Round, 1 3/8”, #4 SS, ”2”
9769447 Plate, Round, 1 3/8”, #4 SS, ”3”
9796540 Plate, Round, 1 3/8”, #4 SS, ”4”
9796642 Plate, Round, 1 3/8”, #4 SS, ”5”
9796745 Plate, Round, 1 3/8”, #4 SS, ”6”
9796848 Plate, Round, 1 3/8”, #4 SS, ”7”
9796940 Plate, Round, 1 3/8”, #4 SS, ”8”
9797040 Plate, Round, 1 3/8”, #4 SS, ”9”
9797749 Plate, Round, 1 3/8”, #4 SS, ”B”
9797075 Plate, Round, 1 3/8”, #4 SS, ”G”
9797841 Plate, Round, 1 3/8”, #4 SS, ”L”
9796976 Plate, Round, 1 3/8”, #4 SS, ”LL”
9797944 Plate, Round, 1 3/8”, #4 SS, ”M”
9797178 Plate, Round, 1 3/8”, #4 SS, ”P”
9796873 Plate, Round, 1 3/8”, #4 SS, ”UL”
9798365 Plate, Round, 1 3/8”, #4 SS, Alarm
9796575 Plate, Round, 1 3/8”, #4 SS, Star 1
9796472 Plate, Round, 1 3/8”, #4 SS, Star 2
9796770 Plate, Round, 1 3/8”, #4 SS, Star G
9796678 Plate, Round, 1 3/8”, #4 SS, Star L
Car Braille
Part No. Print No. Description
9796071
Plate, Round, 1 3/8”, #4 SS, Door Close Rear
Symbol
9796174 Plate, Round, 1 3/8”, #4 SS, Door Close Symbol
9796277
Plate, Round, 1 3/8”, #4 SS, Door Open Rear
Symbol
9796370 Plate, Round, 1 3/8”, #4 SS, Door Open Symbol
