ThyssenKrupp TAC 32 - Station Inspection; Switch Push; Pull

To Next Page

To Previous Page

Owner’s Manual

E2010 THYSSENKRUPP ELEVATOR Printed in USA February, 2010

Traditional Signal Fixtures-19

Push Button

Part No. Print No. Description

9890671 160645 PushButton,White,ADA,Vertical,DownArrow

9890609 160645 PushButton,White,ADA,Vertical,UpArrow

Push Button

Part No. Print No. Description

9818431 171AP1

Switch, V7 Push Button, SPDT, 250 VAC, 10 A and

125 VDC, .5 A

Station Inspection

Part No. Print No. Description

9890531 140158 Inspection Station, Car Top

Switch Push / Pull

Part No. Print No. Description

9810857 108150 Switch Assy, Stop Horizontal, ”Push Stop, Pull Run”

9810845 108155

Switch Assy, Stop Vertical, ”PUSH STOP, PULL

RUN”
