ThyssenKrupp TAC 32 - Vandal Resistant Lantern Intermediate

Owner’s Manual
E2010 THYSSENKRUPP ELEVATOR Printed in USA February, 2010
Vandal Resistant Signal Fixtures-5
Vandal Resistant Lantern
Intermediate
Terminal
45
6
1
2
3
6
ITEM PART NO. PRINT NO. DESCRIPTION
1 160861 Faceplate, Terminal, #4 SS
160862 Faceplate, Terminal, #8 SS
160863 Faceplate, Terminal, #4 Muntz
160864 Faceplate, Terminal, #8 Muntz
2 160865 Faceplate, Intermediate, #4 SS
160866 Faceplate, Intermediate, #4 SS
160867 Faceplate, Intermediate, #4 Muntz
160868 Faceplate, Intermediate, #8 Muntz
3 160629 Bracket, Jewel Mounting
4 138316 Holder, Jewel
5 138313 Jewel, Red
138315 Jewel, Green
6 160511 Fastening Kit, #4 SS
160512 Fastening Kit, #8 SS
160513 Fastening Kit, #4 Muntz
160514 Fastening Kit, #8 Muntz
7 160591 Gong Assembly, 24V (Not Shown)
160590 Gong Assembly, 48V (Not Shown)
