Owner’s Manual
E2010 THYSSENKRUPP ELEVATOR Printed in USA February, 2010
Common Elevator Components-8
Mechanical Switch
69290 (NC), 105701 (NO)
1
2
3
4
5
6
69290 Mechanical Switch (N. C.)
ITEM PART NO. PRINT NO.DESCRIPTION
1 46890 Roller Arm
2 46887 Shaft
3 72712 Truarc #5133
4 9706847 10684 Roller
5 9768695 46889 Tire
6 9892916 69291 Contact Block Assembly
105701 Mechanical Switch (N. O.)
ITEM PART NO. PRINT NO.DESCRIPTION
1 105695 Roller Arm
2 46887 Shaft
3 72712 Truarc #5133
4 9706847 10684 Roller
5 9768695 46889 Tire
6 9857072 105705 Contact Block Assembly
