Vandal Resistant Signal Fixtures-3
Vandall Resistant Pushbutton Assembly
#138585 Illuminated
#138586 Non-Illuminated
1
2
3
4
5
6
7
8
9
ITEM PART NO. PRINT NO. DESCRIPTION
1 138592 Pushbutton, Stainless Steel, Vandal Resistant w/jewel
138588 Pushbutton, Stainless Steel, Vandal Resistant wo/jewel
2 138590 Halo Ring Pushbutton, SS
3 138593 Ring, Retaining, .875”
4 138594 Ring, Retaining, 1.25”
5 130595 Halo, Pushbutton Vandal Resistant
6 129BC1 Base, Mounting
7 228AF2 Cam, Switch
8 292AA1 Cap, Switch
9 292AA1 Switch, SPDT
