INSTALLATION
137
NA30 - Manual - 04 - 2022
Separate operator panel
The solution with projecting assembly and a separate operator panel is particularly suitable for
limited in depth installations.
Cutout dimension and mounting steps concerning the separate operator panel are the same for the
flushing mounting (see previous pages.
A standard direct shielded cable with RJ45 connectors must be used for connections.
Separate-mount.ai
Separate operator panel
F1
D1
RX
TX
F2
F3
F4
F5
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
A20
A21
A22
B1
B2
B3
B4
B5
B6
B7
B8
C1 C2
C4
C3
C5 C6
C7 C8
E1
128.5
110
200
16820
30
5
1525
212.5
170
107
177
ON 41 32 5
TRIP
START
N.4 holes ø 4,5
Separate-mount1.ai
