MEASURES, LOGIC STATES AND COUNTERS
PLC I/O assigned not-matching
MMI module Boot OK/NOT OK
MMI module Run-time OK/NOT OK
MRI module Boot OK/NOT OK
MRI module Run-time OK/NOT OK
MID16-1 module Boot OK/NOT OK
MID16-1 module Run-time OK/NOT OK
MID16-2 module Boot OK/NOT OK
MID16-2 module Run-time OK/NOT OK
PT100 module Boot OK/NOT OK
PT100 module Run-time OK/NOT OK
Current loop module Boot OK/NOT OK
Current loop Run-time OK/NOT OK
Oscillography run-time OK/NOT OK
The diagnostic alarms can be allocated to an output relay; for this purpose the Self-test relay pa-
rameter can be set (K1...K6) inside the Set \ Self-test Relay submenu.
Pilot wire diagnostic
Detailed diagnostic information about the pilot wire are available.
(Read \ Pilot wire diagnostic).
BLIN1 pilot wire breaking diagnostic state ON/OFF
Pilot wire BLIN1 shorted ON/OFF
Selective Block - BLOCK2
The input and output state concerning the selective block are available (Read \ Selective block-
BLOCK2).
Block2 input
Phase protections input selective block state BLK2IN-Iph ON/OFF
Ground protections input selective block state BLK2IN-IE ON/OFF
tB-Iph/IE Elapsed state tB timeout ON/OFF
Block2 output
Starting state of phase protections enabled
for external selective block on output ST-Iph-BLK2 ON/OFF
Starting state of ground protections enabled
for external selective block on output ST-IE-BLK2 ON/OFF
Phase protections output
selective block state BLK2-OUT-Iph ON/OFF
Ground protections
output selective block state BLK2-OUT-IE ON/OFF
Phase and ground protections
output selective block state BLK2-OUT-Iph/IE ON/OFF
Fault recording - SFR
Recording is triggered by one or more causes (up to 8 simultaneous):
Activation (OFF-ON transition) of any relay programmed for trip of protection or control element
External trigger (binary input programmed as Fault trigger)
Twenty events are recorded into a circular FIFO (First In, First Out) buffer.
[1][2]
Following information are stored in every record:
Fault counter
[3]
Date and time
Fault cause (element trip)
RMS value for phase currents I
L1rms-r
, I
L2rms-r
, I
L3rms-r
Fundamental component for phase currents I
L1r
, I
L2r
, I
L3r
Input voltages U
L1r
, U
L2r
, U
L3r
Calculated residual current I
ECr
Fundamental component for unbalance neutral current I
Nr
Displacement angle of unbalance neutral current with respect to I
L1
phase current Phi
Nr
Fundamental component for unbalance compensated current I
NCr
Displacement angle of unbalance compensated current with respect to I
L1
phase current Phi
NCr
Thermal image Dtheta-
r
Phase unbalance current I
2r
Inputs
Outputs
Fault cause info (eg. faulted phase)
Note 1 Fault 0 is the newest fault, while the Fault 19 is the oldest fault
Note 2 Data are stored in non volatile memory; they are held in spite of power down
Note 3 Counter is updated at any new record; it may be cleared by means ThySetter
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
