Thytronic NC20 User Manual

15
NC2 0 - Manual - 01 - 2015
TECHNICAL DATA
3.4 MMI
Display LCD alfanumerico 16x4
LEDs
Quantity 8
ON/fail (green) 1
Start (yellow) 1
Trip (red) 1
Freely allocatable (red) 5
Keyboard 8 keys
3.5 COMMUNICATION INTERFACES
Local port
Connection RJ10
Baud rate 19200 bps
Parity None
Protocol Modbus RTU®
Remote ports
RS485
Connection screw terminals
Baud rate 1200...57600 bps
Protocol ModBus®RTU
IEC 60870-5-103
DNP3
Ethernet 100BaseT
Connection Optical fi ber 1300 nm, ST
100 Base TX, RJ45
Baud rate 100 Mbps
Protocol ModBus®TCP/IP,
IEC61850 - Level A
•
•
•
•


•
•
•
•
•
•
