INSTALLATION
Separate operator panel
The solution with projecting assembly and a separate operator panel is particularly suitable for
limited in depth installations.
Cutout dimension and mounting steps concerning the separate operator panel are the same for the
fl ushing mounting (see previous pages.
A standard direct shielded cable with RJ45 connectors must be used for connections.
