INSTALLATION
Thybus port
In order to extend I/O capability, the Pro_N relays can be customized through external auxiliary mod-
ules; moreover 4...20 mA converter and temperature measuring modules are provided.
The modules do not need external auxiliary supply. It is fed directly by Thybus port.
The Thybus link must be carried out by means category 5 shielded cable with RJ45 connectors.
