SETTING AND COMMISSIONING
SET
NC20_menuset1.ai
Active Profle
A
PROCEED SET MENU’
BASE
In 5 A
Inp 100 A
INn 1 A
INnp 100 A
Un 100 V
Unp 1000 V
fn 50 Hz
Reading RELATIVE
Plant
.................
PROFILE A
MMI
PROCEED PROFILE A MENU’
Min. pulse width
tTR1 150 ms
Mode NO LATCHED
Logic DE-ENERGIZED
K1 relay
K2 relay
K3 relay
K4 relay
K5 relay
Min. pulse width
tTR6 150 ms
Mode NO LATCHED
Logic DE-ENERGIZED
K6 relay
RELAYS
LEDs
Start LED logic
NO LATCHED
Trip LED logic
NO LATCHED
LED 1 logic
NO LATCHED
LED 2 logic
NO LATCHED
LED 3 logic
NO LATCHED
LED 4 logic
NO LATCHED
LED 5 logic
NO LATCHED
SELF-TEST RELAY
Self-test relay -
Minor failure
alarm YES
OFF Delay
tIN1OFF 0 s
IN1 matching None
ON Delay
tIN1ON 0 s
Logic Active-ON
OFF Delay
tIN2OFF 0 s
IN2 matching None
ON Delay
tIN2ON 0 s
Logic Active-ON
BINARY INPUTS
Binary input IN2
Binary input IN1
46N COMPENSATION
PhiC 0 deg
IC 0 INn
IB
IB 1 In
TD
TD Enable OFF
tD 1 min
Relays TD
TD-K -
LEDs TD
TD-L -
37
I< Element
I<< Element
I< Enable OFF
I<def enable OFF
I<def 0.5 In
t<def 1 s
I<BLK1 OFF
I<BF OFF
Relays I<
I<TR-K -
I<ST-K -
I<ST-L -
I<TR-L -
LEDs I<
I<<def enable OFF
I<<def 0.5 In
t<<def 1 s
I<<BLK1 OFF
I<disbyI<< OFF
I<<BF OFF
Relays I<<
I<<TR-K -
I<<ST-K -
I<<ST-L -
I<<TR-L -
LEDs I<<
46
I2> Element
I2>> Element
t2CLP>> 0.1 s
I2>>def enable OFF
I2CLP>>def 5 %
I2>> Enable OFF
I2CLP>> Mode OFF
t2>>def 1 s
I2>>def 5 %
I2>>BLK1 OFF
I2>>BLK2OUT OFF
I2>>BLK2IN OFF
I2>>BF OFF
Relays I2>>
I2>>TR-K -
I2>>ST-K -
I2>>ST-L -
I2>>TR-L -
LEDs I2>>
t2CLP> 0.1 s
I2>def enable OFF
I2CLP>def 5 %
I2> Enable OFF
I2CLP> Mode OFF
t2>def 1 s
I2>def 5 %
I2>BLK1 OFF
I2>BLK2OUT OFF
I2>BLK2IN OFF
I2>BF OFF
Relays I2>
I2>TR-K -
I2>ST-K -
I2>ST-L -
I2>TR-L -
LEDs I2>
Common
27
U< Element
U<< Element
Logic27 OR
U< Enable OFF
U<def enable OFF
U<def 0.5 Un
tU<def 1 s
U<inv enable OFF
U<inv 0.5 Un
tU<inv 10 s
U<BLK1 OFF
U<BF OFF
Type Characteristic
U<Curve DEFINITE
Relays U<
U<TR-K -
U<ST-K -
U<ST-L -
U<TR-L -
LEDs U<
U<<def enable OFF
U<<def 0.5 Un
tU<<def 1 s
U<<BLK1 OFF
U<disbyU<< OFF
U<<BF OFF
Relays U<<
U<<TR-K -
U<<ST-K -
U<<ST-L -
U<<TR-L -
LEDs I<<
Param. setting
enable ON
