Thytronic NC20 User Manual

162
162
NC2 0 - Manual - 01 - 2015
SETTING AND COMMISSIONING
NC20_menuset3.ai
PREVIOUS SET MENU’
PREVIOUS PROFILE A MENU’
SET
PROCEED SET MENU’ PROCEED PROFILE A MENU’
59
U> Element
Common
U>> Element
Logic59 OR
U> Enable OFF
U>def enable OFF
U>def 1 Un
tU>def 1 s
U<inv enable OFF
U>inv 1 Un
tU>inv 10 s
U>BLK1 OFF
U>BF OFF
Type Characteristic
U>Curve DEFINITE
Relays U>
U>TR-K -
U>ST-K -
U>ST-L -
U>TR-L -
LEDs U>
U>>def enable OFF
U>>def 1 Un
tU>>def 1 s
U>>BLK1 OFF
U>disbyU>> OFF
U>>BF OFF
Relays U>>
U>>TR-K -
U>>ST-K -
U>>ST-L -
U>>TR-L -
LEDs U>>
50N/51N
IE> Element
IE>> Element
IE>>> Element
tECLP> 0.1 s
tE>RES 0 s
Type Characteristic:
IE>def enable OFF
IECLP>def 2 IEn
IECLP>inv 2 IEn
IE> Enable OFF
IECLP> Mode OFF
tE>def 1 s
IE>def 1 IEn
IE>inv enable OFF
tE>inv 10 s
IE>inv 1 IEn
IE>BLK1 OFF
IE>BLK2OUT OFF
IE>BLK2IN OFF
IE>BF OFF
IE>Curve DEFINITE
Relays IE>
IE>TR-K -
IE>ST-K -
IE>ST-L -
IE>TR-L -
LEDs IE>
tECLP>>> 0.1 s
tE>>>RES 0 s
IE>>>def enable OFF
IECLP>>>def 2 IEn
IE>>> Enable OFF
IECLP>>> Mode OFF
tE>>>def 1 s
IE>>>def 1 IEn
IE>>>BLK1 OFF
IE>>>BLK2OUT OFF
IE>>>BLK2IN OFF
IE>>>BF OFF
IE>disbyIE>>> OFF
IE>>disbyIE>>> OFF
Relays IE>>>
IE>>>TR-K -
IE>>>ST-K -
IE>>>ST-L -
IE>>>TR-L -
LEDs IE>>>
tECLP>> 0.1 s
tE>>RES 0 s
IE>>def enable OFF
IECLP>>def 2 IEn
IE>> Enable OFF
IECLP>> Mode OFF
tE>>def 1 s
IE>>def 1 IEn
IE>>BLK1 OFF
IE>>BLK2OUT OFF
IE>>BLK2IN OFF
IE>>BF OFF
IE>disbyIE>> OFF
Relays IE>>
IE>>TR-K -
IE>>ST-K -
IE>>ST-L -
IE>>TR-L -
LEDs IE>>
74TCS
74TCS Enable OFF
74TCS-BLK1 OFF
74TCS-ST-K -
74TCS-TR-K -
Relays 74TCS
74TCS-ST-L -
74TCS-TR-L -
LEDs 74TCS
BLOCK2
BLOCK2 INPUT
BLOCK2 OUTPUT
Relays BLOCK2IN
tB-K -
ModeBLIN1 OFF
LEDs BLOCK2IN
tB-L -
tB-IPh 2 s
tB-IE 2 s
Relays BLOCK2OUT
BLK2OUT-IPh-K -
BLK2OUT-IE-K -
BLK2OUT-IPh/IE-K-
ModeBLOUT1 OFF
LEDs BLOCK2OUT
BLK2OUT-IPh-L -
BLK2OUT-IE-L -
BLK2OUT-IPh/IE-L-
tF-IPh 1 s
tF-IE 1 s
tF-Iph/IE 1 s
