Description Parameter Unit Setting range
U<<def Operating time
Value
s
0.03 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
Undercurrent - 37
I< Element
Setpoints
I< Logical block I<BLK1
OFF | ON
I< Start relays I<ST-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
I< Trip relays I<TR-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
I< Start LEDs I<ST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
I< Trip LEDs I<TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Defi nite time
37 First threshold defi nite time
State
OFF | ON
Pickup value
In 0.05 ... 1.00 step = 0.01
I<def Operating time
Value
s
0.04 ... 9.99 step = 0.01
10.0 ... 99.9 step = 0.1
100 ... 200 step = 1
I<< Element
Setpoints
I<< Logical block I<<BLK1
OFF | ON
I<< Start relays I<<ST-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
I<< Trip relays I<<TR-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
I<< Start LEDs I<<ST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
I<< Trip LEDs I<<TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Defi nite time
37 Second threshold defi nite time
State
OFF | ON
Pickup value
In 0.05 ... 1.00 step = 0.01
I<<def Operating time
Value
s
0.04 ... 9.99 step = 0.01
10.0 ... 99.9 step = 0.1
100 ... 200 step = 1
Discharge time - TD
TD Enable TD Enable
OFF | ON
tD Discharge time
Value
min 0.1 ... 100.0 step = 0.1
TD Discharge time relays TD-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
TD Discherge time LEDs TD-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Phase unbalance - 46
I2> Element
Setpoints
I2> Enable I2> Enable
OFF | ON
I2CLP> Mode I2CLP> Mode
OFF | ON - Element blocking | ON - Change setting
I2CLP> Activation time
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
I2> Reset time delay
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
I2> Logical block I2>BLK1
OFF | ON
I2> Input selective block I2>BLK2IN
OFF | ON
