Thytronic NC20 - Page 203

203
NC2 0 - Manual - 01 - 2015
APPENDIX
203
NC2 0 - Manual - 01 - 2015
APPENDIX
Description Parameter Unit Setting range
IE>def Operating time
Value
s
0.04 ... 9.99 step = 0.01
10.0 ... 99.9 step = 0.1
100 ... 200 step = 1
Inverse time
50N/51N First threshold defi nite time
State
OFF | ON
Pickup value
In
0.100 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
IE>inv within CLP IECLP>inv In
0.100 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
IE>inv Operating time tE>inv s
0.02 ... 9.99 step = 0.01
10.0 ... 60.0 step = 0.1
IE>> Element
Setpoints
IE>> Enable IE>> Enable
OFF | ON
IECLP>> Mode IECLP>> Mode
OFF | ON - Element blocking | ON - Change setting
IECLP>> Activation time
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
tE>> Reset time delay
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IE>> Logical block IE>>BLK1
OFF | ON
IE>> Input selective block IE>>BLK2IN
OFF | ON
IE>> Output selective block IE>>BLK2OUT
OFF | ON
IE>> Breaker failure IE>>BF
OFF | ON
IE> Disabling by IE>> start IE>disbyIE>>
OFF | ON
IE>> Start relays IE>>ST-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IE>> Trip relays IE>>TR-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IE>> Start LEDs IE>>ST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
IE>> Trip LEDs IE>>TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Defi nite time
50N/51N Second threshold defi nite time
State
OFF | ON
Pickup value
In
0.100 ... 0.999 step = 0.001
1.00 ... 9.99 step = 0.01
10.0 ... 40.0 step = 0.1
IE>>def within CLP IECLP>>def In
0.100 ... 0.999 step = 0.001
1.00 ... 9.99 step = 0.01
10.0 ... 40.0 step = 0.1
IE>>def Operating time
Value
s 0.03 ... 10.00 step = 0.01
IE>>> Element
Setpoints
IE>>> Enable IE>>> Enable
OFF | ON
IECLP>>> Mode IECLP>>> Mode
OFF | ON - Element blocking | ON - Change setting
IECLP>>> Activation time
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
tE>>> Reset time delay
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IE>>> Logical block IE>>>BLK1
OFF | ON
IE>>> Input selective block IE>>>BLK2IN
OFF | ON
IE>>> Output selective block IE>>>BLK2OUT
OFF | ON
