Description Parameter Unit Setting range
S< Trip LEDs S<TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Remote tripping
Remote tripping relays RemTrip-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Remote tripping LEDs RemTrip-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Pilot wire diagnostic
BLOUT1 Diagnostic pulses period PulseBLOUT1
OFF | 100ms | 1s | 5s | 10s | 60s | 120s
BLIN1 Diagnostic pulses control time interval PulseBLIN1
OFF | 100ms | 1s | 5s | 10s | 60s | 120s
Not received pulses at BLIN signalling relays PulseBLIN-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Not received pulses at BLIN signalling LEDs PulseBLIN-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Demand measures
Fixed demand period tFIX min 1 ... 60 step = 1
Rolling demand period tROL min 1 ... 60 step = 1
Number of cycles for rolling on demand N.ROL
1 ... 24 step = 1
Oscillography
Readings
State
Initialization | Start recording | Acquire | Trigger |
Stopped | Wait | Fail | Off
Records
0 ... 0 step = 0
Buffer storage
% 0 ... 0 step = 0
Trigger Setup
Pre-trigger time
s 0.05 ... 1.00 step = 0.01
Post-trigger time
s 0.05 ... 60.00 step = 0.05
Element pickup trigger
ON | OFF
Trigger from outputs
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Binary input trigger
ON | OFF
Trigger from inputs IN1-IN32
IN1 | IN2 | IN29 | IN30 | IN31 | IN32
Trigger from inputs IN33-IN42
IN33 | IN34 | IN35 | IN36 |
80% Buffer alarm
OFF | ON
Set sample channels
iL1
On | Off
uL1
On | Off
iL2
On | Off
uL2
On | Off
iL3
On | Off
uL3
On | Off
iN
On | Off
Set analog channels
Analog 1
Frequency | IL1rms | IL1 | UL1 | IL2rms | IL2 | UL2 |
IL3rms | IL3 | UL3 | IN | PhiN | INC | PhiNC | IEC | I2
| T1 | T2 | T3 | T4 | T5 | T6 | T7 | T8 | Off
Analog 2
Frequency | IL1rms | IL1 | UL1 | IL2rms | IL2 | UL2 |
IL3rms | IL3 | UL3 | IN | PhiN | INC | PhiNC | IEC | I2
| T1 | T2 | T3 | T4 | T5 | T6 | T7 | T8 | Off
Analog 3
Frequency | IL1rms | IL1 | UL1 | IL2rms | IL2 | UL2 |
IL3rms | IL3 | UL3 | IN | PhiN | INC | PhiNC | IEC | I2
| T1 | T2 | T3 | T4 | T5 | T6 | T7 | T8 | Off
Analog 4
Frequency | IL1rms | IL1 | UL1 | IL2rms | IL2 | UL2 |
IL3rms | IL3 | UL3 | IN | PhiN | INC | PhiNC | IEC | I2
| T1 | T2 | T3 | T4 | T5 | T6 | T7 | T8 | Off
Analog 5
Frequency | IL1rms | IL1 | UL1 | IL2rms | IL2 | UL2 |
IL3rms | IL3 | UL3 | IN | PhiN | INC | PhiNC | IEC | I2
| T1 | T2 | T3 | T4 | T5 | T6 | T7 | T8 | Off
