MEP S.p.A.
1--4
4
Use and maintenance manual TIGER 370 CNC--MR
Techn ical Data
CUTTING SPEEDS
Speed rpm 900
Speed (optional) rpm 600900
Disk blade (HSS type)
External disc diameter mm 370
Internal hole diameter mm 32
Blade thickness mm 3
RATED ELECTRICAL POWER
Head spindle motor Kw 3
Electric coolant pump motor Kw 0,09 x 2
Feed step motor Kw 0,44
Step head motor kW 0,048
Max installed power kW 3.668
SPINDLE MOTOR
No.of poles Current (Volts) Absorption (Amps) Power (Kw) rpm
6 380 8,4 3 940---1130
Stator wound with enamelled copper wire, class H 200° C.
Class F insulation (limit temperature TL 155° C).
IP 54 protection rating (total against contact with live parts, water sprayed from all directions, with shaft oil
seal).
Conforming to CEI norms, publication: IEC 34 of 01/07/1985.
Dimensions
MACHINE INSTALLED
Work table height mm 1000
Weight Kg 1060
