11-- 1
Optional
This chapter provides a list of the available accessories that can be fitted to this
machine, along with assembly instructions.
Accessories available on request
These optional extras must be fitted in the manufacturer’s factory, inasmuch as
they could be difficult for the user to mount by himself. A list of these parts is
provided below.
Chute type bar loader CB 6001
This accessory delivers all the bars on the loader chute in order, giving long
autonomy to the saw even when unattended.
CB 6001 must be ordered with the saw, as it is necessary to enhance the con-
troller and to test it carefully before delivery.
It has a surface of 80 cm with adjustable tilt feature, can be loaded entirely with
circular bars (1) or square bars (2), s olid or tubular, in the dimensions indicated
in the table below:
1 2
LOAD TABLE
Sections
mm 20÷80 20÷100 20÷80 20÷100 130 x h 10÷35 130 x h 10÷100
N.B.
11
