Tiger 370 CNC--MR - Automatic Loop Operating Cycle Modes

MEP S.p.A.
5--30
55
Use and maintenance manual TIGER 370 CNC--MR
Automatic loop operating cycle
" Press F9 to pass to the main menu and change operating mode.
" Press F5 to pass to tha cutting cycle in AUTOMATIC LOOP. This mode ena-
bles the machine to execute cuts with different depths and lengths on the sa-
me bar.
MAIN MENU
F3 = SEMI-AUTOMATIC
F4 = AUTOMATIC
F5 = AUTOMATIC-LOOP
F6 = DIAGNOSTICS
F9 = ZERO SETTING
" Press F7 to select the LOOP mode, that can be single or continuous.
" SINGLE LOOP: this operating mode is used to cut material at preset depths
(P1, P2, P3) and lengths (L1, L2, L3), while the possibility of intervening in
the work cycle on completion of each LOOP executed, is retained.
AUTOMATIC LOOP
X=
θ° =
W=
F = 153
S=
kg= 10
DL= 0
SL= 3
AM= 0.0
A = 0.1
T= 0:0
TT= 0:10
F0 = PGR. SINGLE
F9 = MAIN MENU
F8 = BLADE THICKNESS
F7 = SING/CONT CYCLE
F6 = EXEC. STEP/CONT
CUTS
EXEC.
θ CUTS
PROG.
SINGLE LOOP
PGR. NO
MEASUR. CUTS PROG.
0 905.7 2343
OPERATING CYCLE
FCTI
" CONTIUOUS LOOP: this operating mode is used to obtain preset depths
and lengths of cuts on material, with LOOP repetitions up to 99 times.
AUTOMATIC LOOP
X=
θ° =
W=
F = 153
S=
kg= 10
DL= 0
SL= 3
AM= 0.0
A = 0.1
T= 0:0
TT= 0:10
F0 = PGR. SINGLE
F9 = MAIN MENU
F8 = BLADE THICKNESS
F7 = SING/CONT CYCLE
F6 = EXEC. STEP/CONT
CUTS
EXEC.
θ CUTS
PROG.
PGR. NO
MEASUR.
CUTS PROG.
0 905.7 2343
OPERATING CYCLE
FCTI
SINGLE LOOP
