Appendix A: Miter Jaws
PART
DESCRIPTION
(NUMBER)
QUANTITY
Miter Jaw
(SB3302)
2
An optional set of jaws for measuring mitered parts.
1
2
3
4
1
2
3
4
The TigerSPC Miter Jaws are bi-directional to accommodate dierent miter angles.
Attaching Jaws
There are 4 slots on each foot of the TigerSPC.
Each Jaw has magnets and tabs on the underside to
secure it to a foot.
MagnetsTabs
